SAL4702

Home > Products > Air Brake System > Load Sensing Valve > SAL4702
Model:
Inquiry
Product Description:
SUNDOZ NO:SAL4702
ORG NO:475 721 003 0
  • DAF
    1387214
  • LEYLAND-DAF
    1387214
  • SCANIA
    1935115
Product Specification:
  • Break point
    2 bar
  • Control Pressure
    10 bar
  • Distance between bolts
    26.0 mm
  • Exhaust
    With silencer
  • Inlet Pressure
    10 bar
  • Max. operating pressure
    13 bar
  • Mounting
    2x M10
  • Operational range
    0.3 to 4.65 bar
  • Port thread 1
    M22 x 1.5 JED-388
  • Port thread 2
    M22 x 1.5 JED-388
  • Port thread 4
    M16 x 1.5 JED-388
  • Port thread 41
    M16 x 1.5 JED-388
  • Port thread 42
    M16 x 1.5 JED-388
  • Range of adjustment
    0.3 to 4.65 bar
  • Regulating ratio
    1:5.3
  • Temperature range
    -40°C to +80°C
  • Type
    Pneumatic
  • Type of operation
    Dynamic
  • Calculated Volume (dm³)
    7.0087
  • GTIN
    7895851051232
  • Size (mm x mm x mm)
    265 x 174 x 152
  • Weight (kg)
    1.627
